Monitoring and analysis of benzene series compounds in workplaces of different industries in Jinshan District of Shanghai City

Abstract

Abstract:

Objective To understand the concentration levels of benzene series substances in workplaces in Jinshan District of Shanghai City，and to grasp the types and concentration characteristics of benzene series substances in different industries' workplaces，providing a basis for formulating occupational disease prevention and control strategies. Methods Fixed-point and individual sampling were conducted in 40 enterprises involving benzene series substances in Jinshan District from 2023 to 2024，and the substances were detected by gas chromatography. The results of fixed-point and individual sampling were compared，and the types and concentration characteristics of benzene series substances in different industries were analyzed. Results A total of 40 enterprises were monitored. The pass rate was 70.0% in 2023 and 75.0% in 2024（P>0.05）. In the fixed-point sampling，the pass rate of toluene（99.3%） was higher than that of xylene（82.4%）（P<0.05）. In the individual sampling，all four benzene series substances were qualified. The detection rate of benzene and toluene in individual sampling were higher than that in fixed-point sampling. The concentration of fixed-point sampling in the chemical manufacturing industry，furniture manufacturing industry，metal products industry，automotive manufacturing industry，and rubber and plastic products industry were higher than that of individual sampling. The over-standard sampling points were mainly distributed in the chemical manufacturing industry and automotive manufacturing industry. Among all the monitored industries，the detection rates of toluene，ethylbenzene and xylene were relatively high. Only toluene had a relatively high detection rate in the pharmaceutical manufacturing industry. The concentration of xylene was relatively high in the automotive manufacturing industry and furniture manufacturing industry，while the concentration of toluene was relatively high in the rubber and plastic products industry. The concentration of all benzene series substances was relatively low in the pharmaceutical manufacturing industry and printing industry. The detection rate of benzene was lower than that of the other three benzene series substances，and the concentration of benzene was relatively low in all industries. Conclusion The qualified rate of individual sampling for benzene series monitoring in Jinshan District of Shanghai City is 100.0%，and the occupational exposure risk of benzene series in workers is low. The results of exceeding the standard are all from the fixed point sampling data，so the fixed point sampling and monitoring of enterprises should be strengthened. Focus on the chemical manufacturing industry and develop monitoring programs according to the characteristics of different industries.

Key words: Benzene series, Workplace, Fixed-point sampling, Individual sampling, Industry

CLC Number:

R135.13

WU Yun, YAO Lihong, ZHOU Xuesong, WU Xiaobin, YE Yulong. Monitoring and analysis of benzene series compounds in workplaces of different industries in Jinshan District of Shanghai City. [J]OCCUPATION AND HEALTH, 2026, 42(3): 312-316.

Figures/Tables 8

References 17

[1]	张金月, 娄贺仁, 李培, 等. 2020年天津市苯作业工人血象异常情况及影响因素分析[J]. 职业与健康, 2024, 40(3):316-319.
[2]	NICAS M, NEUHAUS J, HYGIENE E. Predicting benzene vapor concentrations with a near field/far field model[J]. JOEH, 2008, 5(9):599-608.
[3]	何宗剑, 莫玉茗. 苯生物监测指标测定方法的研究进展[J]. 职业与健康, 2024, 40(10):1426-1429.
[4]	许艳丹, 王莉萍, 周雪松, 等. 2016—2021年上海市金山区作业场所苯及苯系物监测结果分析[J]. 上海预防医学, 2023, 35(4):369-373.
[5]	曾东. 煤矿井下粉尘定点区域采样和个体采样检测结果的相关性[D]. 郑州: 郑州大学, 2011.
[6]	王彦梅. 某制鞋厂甲苯定点采样和个体采样的关系[D]. 上海: 复旦大学, 2012.
[7]	张卫娟, 陈洁, 王明. 职业性急性甲苯中毒性脑病6例临床分析[J]. 中国职业医学2015, 42(4):406-407.
[8]	REVILLA A S, PESTANA C R, PARDO-ANDREU G L, et al. Potential toxicity of toluene and xylene evoked by mitochondrial uncoupling[J]. Toxicol Vitro, 2007, 21(5):782-788. DOI URL
[9]	王艳艳, 邵小翠, 姜红梅. 大连市油漆及涂料生产行业甲苯和二甲苯的职业健康风险评估[J]. 职业与健康, 2022, 38(24):3323-3326.
[10]	王倩. 职业接触二甲苯生物限值的研究[D]. 武汉: 武汉科技大学, 2012.
[11]	谢品楠, 陈棋, 许京轩, 等. 苯中毒性脑病的MRI表现[J]. 温州医科大学学报, 2018, 48(7):535-538.
[12]	李登楼. 苯的毒性实验研究[D]. 兰州: 甘肃政法学院, 2016.
[13]	卢俊典, 刘晓杰, 贾婷, 等. 2022年我国甲苯市场综述[J]. 化学工业, 2023, 41(4):31-35,42.
[14]	王池雅, 杨潇, 金梦西, 等. 二苯甲烷合成研究进展[J]. 轻工科技, 2013, 29(7):41-43.
[15]	董熠, 刘丽佳, 韩潞雯, 等. 香豆素类化学成分的药理作用及毒性机制研究进展[J]. 中草药, 2023, 54(16):5462-5472.
[16]	陈惠鹏, 彭建梅, 马争, 等. 2016—2018年东莞市作业场所苯系物监测结果分析[J]. 中国工业医学杂志, 2020, 33(3):253-255.
[17]	吴蔚鹏, 徐晓萍, 蔡英杰. 油漆中主要成膜物质及溶剂的组成研究[J]. 化工时刊, 2024, 38(5):26-29.

苯系物	定点采样			个体采样
苯系物	监测数	合格数	检出数	监测数	合格数	检出数
苯	136	136（100.0）	21（15.4）	136	136（100.0）	38（27.9）
甲苯	136	135（99.3）	100（73.5）	136	136（100.0）	117（86.0）
乙苯	136	136（100.0）	104（76.5）	136	136（100.0）	116（85.3）
二甲苯	136	112（82.4）	107（78.7）	136	136（100.0）	118（86.8）

苯系物	定点采样			个体采样
苯系物	监测数	合格数	检出数	监测数	合格数	检出数
苯	136	136（100.0）	21（15.4）	136	136（100.0）	38（27.9）
甲苯	136	135（99.3）	100（73.5）	136	136（100.0）	117（86.0）
乙苯	136	136（100.0）	104（76.5）	136	136（100.0）	116（85.3）
二甲苯	136	112（82.4）	107（78.7）	136	136（100.0）	118（86.8）

苯系物	定点采样			个体采样
苯系物	监测数（个）	范围	M（P₂₅，P₇₅）	监测数（个）	范围	M（P₂₅，P₇₅）
苯	136	0.20~1.91	0.20（0.20，0.20）	136	0.05~0.11	0.05（0.05，0.05）
甲苯	136	1.00~75.72	1.00（1.00，2.29）	136	0.25~10.39	0.25（0.25，0.25）
乙苯	136	2.00~92.04	2.00（2.00，6.59）	136	0.50~12.56	0.50（0.50，0.50）
二甲苯	136	1.00~442.88	9.55（1.00，28.68）	136	0.25~61.25	0.98（0.25，3.76）

苯系物	定点采样			个体采样
苯系物	监测数（个）	范围	M（P₂₅，P₇₅）	监测数（个）	范围	M（P₂₅，P₇₅）
苯	136	0.20~1.91	0.20（0.20，0.20）	136	0.05~0.11	0.05（0.05，0.05）
甲苯	136	1.00~75.72	1.00（1.00，2.29）	136	0.25~10.39	0.25（0.25，0.25）
乙苯	136	2.00~92.04	2.00（2.00，6.59）	136	0.50~12.56	0.50（0.50，0.50）
二甲苯	136	1.00~442.88	9.55（1.00，28.68）	136	0.25~61.25	0.98（0.25，3.76）

行业	监测数（个）	范围	M（P₂₅，P₇₅）
化学品制造业	134	0.60~538.42	4.99（1.44，18.21）
家具制造业	24	0.60~177.29	7.60（2.42，18.78）
金属制品业	20	0.60~89.75	4.52（0.81，19.29）
汽车制造业	36	0.60~86.58	13.39（3.31，36.07）
设备制造业	28	0.60~86.63	6.35（1.89，30.30）
橡胶和塑料制品业	8	1.62~189.74	17.76（4.70，32.19）
医药制造业	14	0.60~5.50	2.04（0.60，4.20）
印刷业	8	0.60~4.20	2.40（0.60，4.20）
